Required information for service purpose
Plant:
Burner data:
Burner management system LMV50...
Co
ASN Production date Software version
Burner control
Load controller
AZL5...
Air actuator
Gas actuator
Oil actuator
Auxiliary actuator
General data burner management system LMV50...
Date Time Name
Operating hours
Device on
power
Starts
Number of
errors
Gas Oil stage 1 Oil stage 2 Total Oil Gas Total
Lockout history
No. Date Time Code
Diagnostic
code
Error
phase
Startup Load Fuel Description of fault
1
2
3
4
5
6
7
8
9
Error history
No. Class Fuel Code Phase Diagnostic
code
Load Startup Description of fault
1
2
3
4
5
6
7
8
9
10

Note!
Alternative to the tables, a backup for offline operating mode can be stored and send via the ACS450
software.
