Private Communication Systems
Mobile Phones
12.Now you push the antenna in (figure A).
Fasten the connector cover by hooking it into the lower housing section, and
snapping it down until it locks in the upper housing section (figure B).
A B
13.Insert the SIM card rack together with the SIM card.
14.Finally you insert the battery and close the battery
compartment with the battery lid.
15.Now you have assembled the phone completely.
Service Manual C1x V 1.0 PN MP ST
R. Fleuren
Sm_C1x_lvl2_v10_w97.doc Page 11 of 23 09/98
