2. Key Features
Feature Description
Physical Data
• Dimensions: 87 X 44 X 23 mm
• Weight: 90 g
Bands
• Triple band E-GSM 900/ GSM 1800 / GSM1900
• GPRS Multi Class 10
Battery
• Li-ion Battery Pack
• Nominal Voltage : 3.7 V
• Nominal Capacity :750 mAh
• Power Input : 1.8 A (0.6 ms) / 0.1A(4 ms)
Stand-by Time
• Up to 220 hours
Talk Time
• Up to 180 minutes
SIM Card
• Small (“Plug In”) 3V SIM card (Phase II)
• To insert SIM card, the battery pack must be removed.
GSM Antenna
•
triple band PIFA antenna will be an integral part of the
mobile phone.
Receive Sensitivity
• EGSM: -102 dBm
• PCS: -102 dBm
(Specification, static & with fading)
Measurement values are referred to the external antenna
connector.
Transmit Power
• EGSM: nominal 2W (Class 4)
• PCS: nominal 1W (Class 1)
Speech Codec
• Triple Rate (HR/FR/EER) and Adaptive Multi rate are
available as standard
Temperature Range
• -10°C to +55°C (Normal operation)
• -30°C to +85°C (Storage capability)
Display
• Main LCD: 1.8’’; 128x160 262K color TFT LCD
• Sub LCD: 1.0’’; 96x64 color LCD
• Illumination: white LED
Keypad
• 12 digit keys (0-9, #, *)
• 6 function keys (RSK/LSK/Send/End/Display/Extra)
• 5 way Navi-Key
• 4 side keys (Volume +, -/Camera/Hands free
• Illumination color: blue LED
Internet Access
• WAP 2.0 dual stack
Camera
• Integrated camera with attachable FPC
• Resolution: 30K (VGA)
Connectivity
• Serial and IrDA
Video Support
• Recording, playback, packet video, 3GPP; H.263,
MPEG4
Sounds Support
• AAC, AMR-NB, SMAF, SP-Midi, WAV AD-PVM,
40chords polyphonic ring tones (MA3)
Page 5 of 21
Service Repair Documentation
Level 2 – CL75
