Parameter Function Default
P085 Nominal power for motor (kW/hp)
✩✩✩
P086 ● Motor current limit (%) 150
P087 Motor PTC enable 0
P089 ●
Stator resistance (Ω)
✩✩✩
P091 ● Serial link slave address 0
P092 ● Serial link baud rate 6
P093 ● Serial link timeout (seconds) 0
P094 ● Serial link nominal system setpoint
(Hz)
50.00
P095 ● USS compatibility 0
P099 ● Communication adapter type 0
P101 ● Operation for Europe or North America 0
P111 Inverter power rating (kW/hp)
✩✩✩
P112 Inverter type 8
P113 COMBIMASTER model -
P121 Enable/disable RUN button 1
P122 Enable/disable FORWARD/REVERSE
button
1
P123 Enable/disable JOG button 1
P124
Enable/disable ∆ and ∇ buttons
1
P125 Reverse direction inhibit 1
P131 Frequency setpoint (Hz) -
P132 Motor current (A) -
P133 Motor torque (% nominal torque) -
P134 DC link voltage (V) -
P135 Motor RPM -
P137 Output voltage (V) -
P140 Most recent fault code -
P141 Most recent fault code –1 -
P142 Most recent fault code –2 -
P143 Most recent fault code –3 -
P151 ● Green LED function 4
Parameter Function Default
P152 ● Yellow LED function 5
P201 PI closed loop mode 0
P202 ● P gain (%) 1.0
P203 ● I gain (%) 0.00
P205 ● Sample interval (x 25 ms) 1
P206 ● Transducer filtering 0
P207 ● Integral capture range (%) 100
P208 Transducer type 0
P210 Transducer reading (%) -
P211 ● 0% setpoint 0.00
P212 ● 100% setpoint 100.00
P220 PI frequency cut-off 0
P331 Analogue mode 2
P332 Fine adjustment (%) 10
P723 State of digital inputs -
P845
Motor current limt for flying start
(V3.00)
50
P910 ● Local/Remote mode 0
P922 Software version -
P923 ● Equipment system number 0
P930 Most recent fault code -
P931 Most recent warning type -
P944 Reset to factory default settings 0
P971 ● EEPROM storage control 1
P986 Relay Output 0
WARNING
Please refer to the Reference Manual before changing any parameters.
