Technical specifications
CP 5612
22 Operating Instructions, 05/2021, C79000-G8976-C278-04
Technical specifications of the CP 5612
Shock, operating
(EN 60068-2-27)
Half sine
Time
Number of shocks
50 m/s
2
(5 g)
30 ms
100/axis
Design, dimensions and weight
Module format
Flat module
Short PCI card
Weight
98 g
Dimensions (W x H x D) in mm
18 x 107 x 125
Electromagnetic compatibility
Emission
• to EN 55022
•
to FCC
Class B
Class B
Immunity
On signal cables
• Surge to EN 610004-5
•
Burst to EN 61000-4-3
±2 kV
±2 kV
to discharge of static electricity
• Contact discharge to IEC 61000-4-
2
±6 kV
to radiated radio frequencies
• to EN 61000-4-3
10 V/m at 80 MHz to 2 GHz
10 V/m, 50% on-load factor at 900 MHz and
1.89 GHz
• to EN 61000-4-6
10 V/m, 80% amplitude modulation at
1 kHz, 10 kHz to 80 MHz
