Siemens CPU 1518-4 PN/DP ODK - Page 43

Technical specifications
CPU 1518-4 PN/DP ODK (6ES7518-4AP00-3AB0)
Manual, 09/2016, A5E35681108-AA
43
6ES7518-4AP00-3AB0
3rd interface
Interface hardware
Number of ports
1
Integrated switch
No
RJ45 (Ethernet)
Yes; X3
Protocols
PROFINET IO controller
No
PROFINET IO device
No
SIMATIC communication
Yes
Open IE communication
Yes
Web server
Yes
4th interface
Interface hardware
Number of ports
1
RS 485
Yes; X4
Protocols
PROFIBUS DP master
Yes
PROFIBUS DP slave
No
SIMATIC communication
Yes
Interface hardware
RJ45 (Ethernet)
100 Mbps
Yes
1000 Mbps
Yes; only possible on the X3 interface of CPU
1518
Autonegotiation
Yes
Autocrossing
Yes
Industrial Ethernet status LED
Yes
RS 485
Transmission rate, max.
12 Mbps
Protocols
Number of connections
Number of connections, max.
384; via integrated interfaces of the CPU and
connected CPs/CMs
Number of connections reserved for ES/HMI/Web
10
Number of connections via integrated interfaces
192
Number of S7 routing connections
64; in total, only 16 S7 routing connections are
supported via PROFIBUS
SIMATIC communication
S7 communication, as server
Yes
S7 communication, as client
Yes
User data per job, max.
See online help (S7 communication, user data
size)
