Siemens CPU 312C User Manual

Technical data of CPU 31x
7.2 CPU 312
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
7-7
Technical data
Interface power supply
(15 to 30 VDC)
Max. 200 mA
Functionality
• MPI
Yes
• PROFIBUS DP
No
• Point-to-point connection
No
MPI
Services
• PG/OP communication
Yes
• Routing
No
• Global data communication
Yes
• S7 basic communication
Yes
• S7 communication
– As server
– As client
Yes
No
• Transmission rates
187.5 Kbaud
Programming
Programming language LAD/FBD/STL
Instruction set See the Instruction List
Nesting levels 8
System functions (SFC) See the Instruction List
System function blocks (SFB) See the Instruction List
User program protection Yes
Dimensions
Mounting dimensions W x H x D (mm) 40 x 125 x 130
Weight 270 g
Voltages, currents
Power supply (rated value) DC 24 V
• Permissible range
20.4 V to 28.8 V
Current consumption (no-load operation) Typically 60 mA
Making current Typically 2.5 A
Power consumption (nominal value) 0.6 A
I
2
t 0.5 A
2
s
External fusing of power supply lines
(recommended)
Min. 2 A
Power loss Typically 2.5 W

Siemens CPU 312C Specifications

General

Brand	Siemens
Model	CPU 312C
Category	Processor
Language	English
