Siemens CPU 312C User Manual

Operating and display elements
2.2 Operating and display elements: CPU 31x
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
2-5
2.2 2.2 Operating and display elements: CPU 31x
2.2.1 Operating and display elements: CPU 312, 314, 315-2 DP:
Operating and display elements
; ;
1
2
3
4
5
6
)5&(
05(6
6723
581
6723
581
'&9
%)
6)
00&
The figures show the following CPU elements
(1) Slot for the SIMATIC Micro Memory Card (MMC) incl. the ejector
(2) 2. Interface X2 (only for CPU 315-2 DP)
(3) Power supply connection
(4) 1. Interface X1 (MPI)
(5) Mode selector switch
(6) Status and error displays
