Technical data of CPU 31x
7.4 CPU 315-2 DP
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
7-15
Technical data
Operable function modules and communication
processors
• FM
Max. 8
• CP (PtP)
Max. 8
• CP (LAN)
Max. 10
Time
Clock Yes (HW clock)
• Buffered
Yes
• Buffered period
Typically 6 weeks (at an ambient temperature of
40 °C)
• Behavior of the clock on expiration of the
buffered period
The clock keeps running, continuing at the time-
of-day it had when power was switched off.
• Accuracy
Deviation per day: < 10 s
Operating hours counter 1
• Number
0
• Value range
2
31
hours
(if SFC 101 is used)
• Granularity
1 hour
• Retentive
Yes; must be manually restarted after every
restart
Time synchronization Yes
• In the PLC
Master
• On MPI
Master/slave
S7 message functions
Number of stations that can log in for signaling
functions (e.g. OS)
16
(depends on the number of connections
configured for PG / OP and S7 basic
communication)
Process diagnostics messages Yes
• Simultaneously enabled interrupt S blocks
40
Test and startup functions
Status/control variables Yes
• Variables
Inputs, outputs, memory bits, DBs, timers,
counters
• Number of variables
– Of those as status variable
– Of those as control variable
30
30
14
Force
• Variables
Inputs/outputs
• Number of variables
Max. 10
Block status Yes
Single-step Yes
Breakpoints 2
