CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
7-1
Technical data of CPU 31x
7
7.1 7.1 General technical data
7.1.1 Dimensions of CPU 31x
Each CPU features the same height and depth, only the width dimensions differ.
• Height: 125 mm
• Depth: 115 mm, or 180 mm with opened front cover.
Figure 7-1 Dimensions of CPU 31x
