Siemens CPU 317-2 PN/DP - Operating and Display Elements: CPU 31 X-2 PN;DP

Operating and display elements
2.2 Operating and display elements: CPU 31x
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
2-9
2.2.3 Operating and display elements: CPU 31x-2 PN/DP
Operating and display elements
1 2 3
4
5
6
7
8
00&
%)
;
0$&$''
;;;
;;;
5;
7;
/,1.
;
6723
581
)5&(
'&9
6)
%)
05(6
6723
581
The figures show the following CPU elements
(1) Bus error indicators
(2) Status and error displays
(3) Slot for the SIMATIC Micro Memory Card (MMC) incl. the ejector
(4) Mode selector switch
(5) Status display of 2nd interface (X2)
(6) 2. Interface X2 (PN)
(7) Power supply connection
(8) 1. Interface X1 (MPI/DP)
