Siemens DAC-NET - Electrical Ratings

A24205-A334-B839 (Edition 14) s
P/N 315-035100-14
14
ACCESSORY PACK (shipped with DAC-NET)
Item Part No.
SBT Munich
Part No.
SBT Florham Park
2 CAN Terminators C24235-A1-K2 P/N 110-134215
2 ASI Terminator C24235-A1-K1 Not Available
1 Can Termination Resistor
120 Ohms
C24235-A1-K12 P/N 140-034723
1 External Alarm EOL Resistor
3.3K Ohms
C24235-A1-K14 P/N 140-034721
1 External Alarm Resistor
680 Ohms
C24235-A1-K13 Not Available
1 Anti-Interference Capacitor
6.8µF / 100V bipolar
C24235-A1-K19 Not Available
ELECTRICAL RATINGS
Power Consumption DAC-NET
24V Back Plane Current 230 mA
24V Screw Terminal Current 0
6.2V Back Plane Current 0
24V Standby Current 230 mA
