Recommended diameter of receptacles
(in cm)
Depending on the model:
Depending on which model you have purchased, your
cooking hob may include a very useful extra cradle
receptacles with diameters of over 26 cm, barbecue
griddles, earthenware cooking pots and all kinds of
concave receptacles (Chinese woks, etc.) Fig. 2.
Pan support for coffee pot: Depending on the model,
your cooking hob may include an additional coffee pot
support, which is exclusively for use on the auxiliary
burner with receptacles of a diameter smaller than
10 cm.
The manufacturer declines all responsibility if these
additional pan supports are not used or are used
incorrectly.
Additional
pan supports:
7
Fig. 2.
22 cm
> 22 cm
BURNER
MINIMUM Ø OF RECEPTACLE MAXIMUM Ø OF RECEPTACLE
Quick burner:
Medium fast:
Auxiliary burner:
Double flamme B:
2,80 kW
Double flamme C: 3,80 kW
Double flamme D: 4,25 kW
Electric hot plates:
16 cm
22 cm
22 cm
14 cm
12 cm
18 cm
28 cm
22 cm
28 cm
26 cm
20 cm
14 cm
Double flamme A: 3,80 kW
support for use on the double-flame burner for
An orange-coloured flame is normal and it is
produced in the presence of dust in the atmosphere,
spillages, etc.
