Release 09/02 Testing the Project
ProTool Co nfig ur ing Win do ws-bas ed S yste ms 4–3
Start Up Instr uctions
Defining settings on the operating unit
• Activate Download mode on the operating unit:
The Download mode setting is dependent on the respective operating unit. In the
case of Windows CE units (except TP 170A), Download mode is activated by
means of an applet in the Control Panel. In the case of other units, e.g. PC and TP
170A, Download mode can be activated from the Loader menu while the unit is
starting up.
The storage location for project file and source file has a default setting.
Note
The download type selected in ProTool and set on the operating unit must match.
Downloading using ProTool
• Sel e ct menu item s "Fil e" > "Downl oad" > "Setti ng..."
• Define the download settings:
Select between serial download (RS232), MPI PROFIBUS DP, USB, Ethernet or
Filecopy (PC only)
• Define the transfer settings:
• Press this button to trigger the downloading process or select menu items
"File" > "Download" > "Start Project Download"
The project file is downloaded.
When the downloading process is completed successfully, the "*.fwd" file is located on
the operating unit in the directory specified.
On completion of downloading, the operating unit is rebooted and the start screen is
displayed.
If downloading is not completed error-free, the corresponding messages are displayed
in the "system message window" under "Download".
