Extend Project with Simple Objects Release 09/02
5–2 ProTool Co nfig ur ing Win do ws-bas ed S yste ms
Start Up Instr uctions
Adding descriptive text to the new screen
• Click on the Text icon in the screen editor
• Click on the required position in the screen
• Enter the text "Second screen"
Configuring a Change of Screens
Configuring switching to the second screen
• Create a Status button in the start screen, as described on Page 3–5 and label
it "2", for example
• In the "Properties" dialog box, click on the Status button on the "Functions" tab control
• Select "Select Object"and open the "Screens" folder
• Double click on "Select_screen"
• Select the name of the second screen, e.g. "PIC_2" in "Screen Name"
