5
Building Technologies
Fire Safety
A6V10207176_h_en_--
2016-05-23
Function features
κ The FC724 is a compact fire control panel with integrated operating unit for
processing signals from FD720 devices.
κ The control panel may be used as a standalone unit or networked.
κ The control panel and the fire detection system are custom-configured using
the Cerberus-Engineering-Tool software.
κ All detector lines are monitored for ground faults.
κ Customer texts can be adapted directly on the operating unit of the control
panel or with the Cerberus-Engineering-Tool software.
κ Up to 2000 events can be retrieved from the event memory based on various
criteria.
κ Automatic summer/winter time changeover
κ Siemens danger management system can be connected
Function elements
Operating unit
The following elements are available on the operating unit:
– CPU module and electronics
– Ethernet connection
– Slots for RS232 and RS485 modules and network modules (SAFEDLINK)
– Space for 'Kaba' or 'Nordic' key switch
– Space for event printer
– Peripheral data bus connection for optional LED modules
Periphery board
The following elements are available on the periphery board:
– Connection terminals for C-NET lines, remote transmission (alarm, fault), horn
output, configurable control inputs and outputs, monitored alarm and fault output,
emergency supply, power supply
– Two slots for loop extension (C-NET)
Power supply unit 150 W, emergency power supply
The power supply feeds the hardware and charges the batteries.
In the event of a power cut, the batteries provide emergency current.
Housing
A pivoting mounting plate can be fitted for the following elements above the periphery
board on the rear housing panel:
– 1x fire brigade periphery module (for Germany)
– 2x sounder modules (as an alternative to mounting on U-rail TS35)
Configuration
The FXS7212 Cerberus-Engineering-Tool allows the system to be customized.
