45
Figure 37: Typical vacuum interrupter contact life curves
100,000
50,000
20,000
10,000
5,000
2,000
1,000
500
200
100
50
20
10
Permissible operating cycles
Load graph "A" vacuum interrupter type VS-17006
Breaking current (symmetrical value)
1 2 5
50 100
10
20
18
2325
Note: Right-hand vertical segment of curve is located at the maximum symmetrical interrupting current rating of the circuit breaker, as
indicated in Table 3: Typical vacuum interrupter contact life and stroke on page 44.
