56
Figure 42: Vacuum interrupter replacement illustration
20.0
Upper pole-support (pole-head)
28.0
Strut
28.1
Centering ring
29.1
Flexible connector
29.2
Terminal clamp
29.3
Spacer (or shoulder)
30.0
Vacuum interrupter
31.2
Upper terminal-bolt
20.0
36.1
Moving terminal
36.3
Eye bolt (or adapter)
40.0
Lower pole-support (pole-bottom)
48.0
Insulating coupler
48.5
Pin
48.6
Angled lever
48.9
Drive link
31.2
28.0
30.0
28.1
48.0
48.6
48.5
48.9
40.0
36.3
36.1
29.2
29.3
29.1
