Overhaul
Figure 42: Vacuum interrupter replacement illustration
20.0
20.0 - Upper pole-support (pole-head)
28.0 - Strut
28.1 - Centering ring
29.1 - Flexible connector
29.2 - Terminal clamp
29.3 - Spacer (or shoulder)
30.0 - Vacuum interrupter
31.2 - Upper terminal-bolt
31.2
28.0
30.0
28.1
29.3
29.1
29.2
36.3
40.0 48.648.5
36.1
48.048.9
36.1 - Moving terminal
36.3 - Eye bolt (or adapter)
40.0 - Lower pole-support (pole-bottom)
48.0 - Insulating coupler
48.5 - Pin
48.6 - Angled lever
48.9 - Drive link
56
