Siemens GMSG

Appendix
Circuit
breaker type
1
Nominal
voltage class
Nominal
three-phase
MVA class
9
Maximum
design
voltage (V)
2
Continuous
current
4
Voltage range
factor (K)
3
Withstand voltage levels Short-
circuit
(at rated
maximum
design
voltage)
(I)
5, 6, 10
Interrupting
time
11
Permissible
tripping
delay (y)
Rated
maximum
design
voltage (V)
divided by
K
(= V/K)
Max. sym.
interrupting
(K x I)
7
Short-time
current (I)
(three
seconds)
Closing and latching
(momentary)
Circuit
breaker
type
1
kV MVA kV rms A rms ---- Power
frequency
kV rms
Lightning
impulse (BIL)
kV crest
kA rms sym ms/cycles Sec kA rms kA rms sym kA rms Asymmetrical
(1.6 x k x I)
8
kA rms
Peak
(2.7 x
k x I)
8
kA peak
5-GMSG-250-
xxxx-97
4.16 250 4.76 1,200, 2,000 1.24 19 60 29 83/5 2 3.85 36 36 58 97
5-GMSG-250-
xxxx-97
5-GMSG-350-
xxxx-132
4.16 350 4.76
1,200, 2,000,
3,000, 4,000FC
1.19 19 60
41 83/5 2 4.0 49 49 78 132
5-GMSG-350-
xxxx-132
7-GMSG-500-
xxxx-111
7.2 500 8.25 1,200, 2,000 1.25 36 95 33 83/5 2 6.6 41 41 66 111
7-GMSG-500-
xxxx-111
15-GMSG-500-
xxxx-62
13.8 500 15.0 1,200, 2,000 1.30 36 95 18 83/5 2 11.5 23 23 37 62
15-GMSG-
500-
xxxx-62
15-GMSG-750-
xxxx-97
13.8 750 15.0
1,200, 2,000,
3,000, 4,000FC
1.30 36 95 28 83/5 2 11.5 36 36 58 97
15-GMSG-
750-
xxxx-97
15-GMSG-
1,000-xxxx-130
13.8 1,000 15.0
1,200, 2,000,
3,000, 4,000FC
1.30 36 95 37 83/5 2 11.5 48 48 77 130
15-GMSG-
1,000-xxxx-
130
8.
Current values in this row are independent of
operating voltage up to and including rated
maximum voltage.
9.
Nominal three-phase MVA class" is included for
reference only. This information is not listed in
ANSI C37.06-1987.
10.
Standard duty cycle is O - 15s - CO.
11.
Standard rating interrupting time is five-cycles
(83 ms). Optional rated interrupting time of
three-cycles (50 ms) is available (except with
24 Vdc tripping).
