en Appliance door
28
2.
Place a folded-up tea towel in the appliance door.
3.
Close the appliance door.
4.
Pull the front pane up and out.
5.
Place the front pane down on a flat surface with the
door handle facing down.
6.
Press the intermediate pane against the appliance
with one hand while pushing the left- and right-hand
retainers upwards. Do not detach the retainers .
7.
Remove the intermediate pane.
8.
WARNING‒Risk of serious harm to health!
If the screws are undone, the safety of the appliance
can no longer be guaranteed. Microwave energy
may escape.
▶ Never undo the screws.
Never unscrew the four black screws on the frame.
22.3 Fitting the door panes
WARNING‒Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
▶ Keep your hands away from the hinges.
Components inside the appliance door may have sharp
edges.
▶ Wear protective gloves.
1.
Turn the intermediate pane until the arrow is in
the top right.
2.
Insert the intermediate pane into the retainer at
the bottom and push it in firmly at the top.
3.
Push the left- and right-hand retainer downwards
until the intermediate pane is clamped .
4.
Attach the front pane downwards into the left- and
right-hand retainers .
5.
Push the front pane to the appliance until the left-
and right-hand hook is opposite the support .
6.
Push the front pane in at the bottom until you
hear it click into place.
7.
Open the appliance door slightly and remove the
tea towel.
8.
Screw both screws back in on the left and right of
the appliance door.
