Siemens KI51FADE0 - Fitting the partition and cover; Telescopic rails; Removing telescopic rails; Installing telescopic rails

Cleaning and servicing en
45
Fitting the partition and cover
1. Insert the cover for the fruit and ve-
getable container.
2. Set the humidity controller to a low
humidity setting.
3. Insert the partition.
→Fig.
10
Telescopic rails
You can remove the telescopic rails
in order to clean them thoroughly.
Removing telescopic rails
1. Pull out the telescopic rail.
→Fig.
11
2. Move the lock in the direction of
the arrow and loosen the pin
from the rear ⁠.
→Fig.
12
3. Push in the telescopic rail.
4. Push the telescopic rail backwards
above the rear pin and disen-
gage ⁠.
→Fig.
13
Installing telescopic rails
1. Place the extended telescopic rail
on the front pin and pull it for-
wards slightly to lock in place ⁠.
→Fig.
14
2. Place the telescopic rail on the
rear pin and push the locking
mechanism back ⁠.
→Fig.
15
