Siemens LC67KHM60 User Manual

en Important safety information
12
Note: We recommend fitting the appliance such that the
lower edge of the glass screen is in line with the lower
edges of the adjacent wall-hung cabinets. Make sure
that the specified safety clearances from the hob are
complied with.
(Important safety
information
Important safety information Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
The appliance can only be used safely if it is
correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly at
its installation location.
Caution!
Damage to the appliance
The surfaces of the appliance are sensitive.
Avoid damaging them during installation.
The width of the extractor hood must
correspond at least with the width of the hob.
For the installation, observe the currently valid
building regulations and the regulations of the
local electricity and gas suppliers.
:Warning
Risk of fire!
Fatty deposits in the grease filter may catch
fire. The specified safety clearances must be
complied with in order to prevent a build-up of
heat. Refer to the information provided for your
cooker. If gas and electric hobs are being
operated together, the largest specified
clearance applies.
:Warning
Risk of fire!
Grease deposits in the grease filter may catch
fire. Never work with naked flames close to the
appliance (e.g. flambéing). Do not install the
appliance near a heat-producing appliance for
solid fuel (e.g. wood or coal) unless a closed,
non-removable cover is available. There must
be no flying sparks.
When conveying the exhaust air, official and
legal regulations (e.g. state building
regulations) must be followed.
" #

Siemens LC67KHM60 Specifications

General

Noise level	67 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Noise level (low speed)	48 dB
Maximum extraction power	660 m³/h
Noise level (high speed)	68 dB
Maximum recirculating power	570 m³/h
Minimum distance from gas hob	600 mm
Noise level (intensive speed)	74 dB
Fluid dynamic efficiency class	A
Grease filtering efficiency class	C
Minimum distance from electric hob	450 mm
Type	Wall-mounted
Cord length	1.3 m
Control type	Touch
Product color	Black, Stainless steel
Built-in display	No
Compatible products	CE, VDE
Exhaust connection diameter	120 mm
Bulb type	LED
Bulb power	1.5 W
Illuminance	90 lx
Number of bulbs	2 bulb(s)
Grease filter type	Aluminum
Current	10 A
Motor power	- W
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	52.5 kWh

Weight and Dimensions

Depth	499 mm
Width	590 mm
Height	- mm
Weight	27000 g
Height (max)	1198 mm
Height (min)	928 mm
Height without chimney	323 mm
