6
Operating modes
This appliance can be used in exhaust-air mode or circulating-
air mode.
Exhaust air mode
Note: The exhaust air must not be conveyed into a functioning
smoke or exhaust gas flue or into a shaft which is used to
ventilate installation rooms which contain heating appliances.
■ Before conveying the exhaust air into a non-functioning
smoke or exhaust gas flue, obtain the consent of the heating
engineer responsible.
■ If the exhaust air is conveyed through the outer wall, a
telescopic wall box should be used.
Air recirculation
Note: To bind odours in air recirculation mode, you must install
an activated carbon filter. The different options for operating the
appliance in air recirculation mode can be found in the
brochure. Alternatively, ask your dealer. The required
accessories are available from specialist retailers, from
customer service or from the Online Shop.
Getting to know the appliance
Here, you can get to know your appliance and receive
information about the accessories.
Control panel
The air which is drawn in is cleaned by the
grease filters and conveyed to the exterior by a
pipe system.
The air which is drawn in is cleaned by the
grease filters and an activated carbon filter,
and is conveyed back into the kitchen.
1 Control panel
2 Light
3 Filter cover
Explanation
1 Retract/extend the appliance, switch the fan on and off
2 Switch on lighting
3 Turn the fan down
4 Display panel
5 Switch fan setting up
6 Intensive setting
7 Fan run-on time
