Siemens LGA63.191A27 Datasheet

6/11
Siemens Building Technologies CC1N7418en
HVAC Products 08.04.2004
Technical data
Mains voltage
- Only with LGA63...
AC 220 V −15 %...AC 240 V +10 %
AC 100 V –15 %...AC 110 V +10 %
AC 230 ±10 %
Mains frequency 50...60 Hz ±6 %
Power consumption 3 VA
Input current at terminal 1 max. 5 A
Perm. electrical rating
- Terminals 4 and 8
- Terminals 6, 7 and 9
- Terminals 5 and 10
max. 4 A
max. 2 A
max. 1 A
External primary fuse max. 10 A (slow)
Degree of protection IP 40 (when integrated)
Perm. mounting position optional
Weight approx. 180 g
Transport
DIN EN 60 721-3-2
Climatic conditions class 2K2
Mechanical conditions class 2M2
Temperature range -50...+60 °C
Humidity < 95 % r.h.
Operation
DIN EN 60 721-3-3
Climatic conditions class 3K5
Mechanical conditions class 3M2
Temperature range 0...+60 °C
for LGA41.173A27 and LGA52.171B27:
-20...+60 °C
Humidity < 95 % r.h.
Condensation, formation of ice and ingress of water are not permitted!
Voltage between ionization probe and
ground
mains voltage
Required detector current min. 5 µA
Possible detector current max. 100 µA
Length of detector cable max. 20 m (separate cable)
Required insulation resistance between
ionization probe with its cable and ground
min. 50 MΩ
General unit data
Environmental
conditions
Flame supervision with
ionization probe
