Technical data
Mains voltage AC 230 V +10 % / -15 %
AC 120 V +10 % / -15 %
Mains frequency 50...60 Hz ±6 %
External primary fuse (Si) 6.3 A (slow)
Power consumption 12 VA
Perm. mounting orientation Optional
Weight Approx. 200 g
Safety class
I (burner control with plug-in base)
Degree of protection IP40 (to be ensured through mounting)
Cable lengths
∂ QRB1 / QRB3 Max. 10 m at 100 pF/m (laid separately)
∂ QRB4 Max. 3 m at 100 pF/m (laid separately)
∂ QRC Max. 10 m at 100 pF/m (laid separately)
Detector cable laid separately Max. 10 m
Remote reset laid separately Max. 20 m
Perm. current at cosι ″ 0.6 LMO14 LMO24 LMO44
Terminal 1 Max. 5 A Max. 5 A Max. 5 A
Terminals 3 and 8 Max. 3 A Max. 3 A Max. 3 A
Terminals 4 and 5 Max. 1 A Max. 1 A Max. 1 A
Terminal 6 Max. 1 A Max. 2 A Max. 2 A
Terminal 10 Max. 1 A Max. 1 A Max. 1 A
Storage DIN EN 60721-3-1
Climatic conditions Class 1K3
Mechanical conditions Class 1M2
Temperature range -20...+60 °C
Humidity <95 % r.h.
Transport DIN EN 60721-3-2
Climatic conditions Class 2K2
Mechanical conditions Class 2M2
Temperature range -20...+60 °C
Humidity <95 % r.h.
Operation DIN EN 60721-3-3
Climatic conditions Class 3K3
Mechanical conditions Class 3M3
Temperature range
- LMO14 / LMO24
- LMO44
-5...+60 °C
-20...+60 °C
Humidity <95 % r.h.
Installation altitude Max. 2,000 m above sea level
Attention!
Condensation, formation of ice and ingress of water are not permitted! If this is
not observed, there is a risk of loss of safety functions and a risk of electric
shock.
General unit data
Environmental
conditions
