Oil Burner Controls LOA2...
LOA3...
Oil burner controls for the supervision, startup and control of 1- or 2-stage forced
draft oil burners in intermittent operation. Oil throughput of less than 30 kg/h.
The LOA2... / LOA3... and this Data Sheet are intended for use by OEMs which
integrate the oil burner controls in their products.
Use, features
Use
General features
Specific features
CC1N7118en
19.05.2016
The LOA... are used for the startup, supervision and control of 1- or 2-stage forced draft
oil burners in intermittent operation.
Yellow-burning flames are supervised with photoresistive detectors QRB..., blue-
burning flames with blue-flame detectors QRC...
 Applications in accordance with EN 267: Automatic forced draft burners for liquid
fuels
 Type-tested and approved in accordance with DIN EN 230:1991
- Undervoltage detection
- Bridging contact for oil preheater (not with LOA28.173A27)
- Special versions including models for incinerator plants and flash-steam generators
- LOA36... with color display of flame intensity and operating

Note!
Donot use for new designs.
