SIEMENS PTE LTD
M65 Level 2 Service Manual
Copyright © Siemens Pte Ltd. Siemens Technical Support Centre
All Rights Reserved May 2004
ICM MP CCQ SLI RHQ Page 6 of 37 Company Confidential
Display
• Type: Full Graphic
• Resolution: 132 x 176 Pixel
• Color depth: 65K
• Technology: TFT (Sharp); TFD (Epson)
• Active area: 31.284mm x 41.712mm
• Pixel size: 0.079mm x 0.237mm. (1 Pixel consists of 3
sub-pixels in red, green and blue)
• Illumination: White LED (3 LEDs integrated)
• Contrast: Adjustable
• Frame rate: 15 frames/seconds
Keypad
• 12-digit block (0-9, #, *)
• Two illuminated function keys (SEND, END)
• IMF Technology @ keys: 2-5-8-0-send-end-soft-navy
• Silicon printed @ keys: 1-4-7-*-3-6-9-#
• ON/OFF key combined with the END key; the symbol ¢ (I
inside O) is used as a symbol for ON/OFF.
• 5 way-joystick with printable design-cap (transparent soft
material)
• 2 soft-keys for different SW-enabled functions
• red display illumination colour
• tactile finder on key “5“
• 6 red LEDs for keypad
Acoustics
• Three-in-one-loudspeaker (water protected) for handset,
handsfree and ringing tones
• Omni-directional microphone (water protected)
• Loud signal emitter (sound ringer) (>100dB(A) SPL @5cm,
'Hongkong-Spec.') for dedicated sound signals
• Polyphonic ringer tones (parallel to GPRS: 16 voices; all
other Use Cases: 32 voices)
• Hands free mode
• Different selectable volume levels for handsfree, handset
and ringer mode (for the amount see SW product
description)
Internet Access
• Wap 2.0 Dual stack
Camera
• Integrated VGA photo & video camera (5x digital zoom,
up to 12 f/s)
Connectivity
• USB, Serial, and IrDA
Night Design
• 2 red LEDS (side shooter) on the side of the phone
(north)
