Siemens M65 Service Manual

SIEMENS PTE LTD
M65 Level 2 Service Manual
Copyright © Siemens Pte Ltd. Siemens Technical Support Centre
All Rights Reserved May 2004
ICM MP CCQ SLI RHQ Page 5 of 37 Company Confidential
3 Key Features
Bands
• Triple Band E-GSM 900 / GSM 1800 / GSM 1900
• GPRS Multi Class 10
Battery
• Li-Ion Battery Pack
• Nominal Voltage : 3.7V
• Nominal Capacity : 780 mAh
• GSM Capacity : 750 mAh
• Power Input : 2.0A (0.6 ms) / 0.25A (0.4 ms)
• Cut-off Threshold : 3.2V
Stand-by Time
• 60 h to 250 h (approx. 3mA quiescent current)
Talk Time
• 100 min to 300 min
SIM Card • Small (”Plug In”) 3V SIM card (Phase II)
•
To insert the SIM card, the battery pack must be
removed.
GSM Antenna • A triple band PIFA antenna will be an integral part of the
mobile phone.
Dimensions
• 109 x 49 x 19 mm (L x W x H)q
Volume
• 89 cm³
Weight
• 104 g
Charging time
• < 2 h for 100%
Storage
• Up to 11 MByte
Transmitter Power
• EGSM: nominal 2W (Specification: Class 4 Mobile
phone)
• PCN and PCS: nominal 1W (Specification: Class 1
Mobile phone)
Transmitter output characteristics is according to GSM 11.10
specification implying all specified operating conditions
(temperature, battery level ...).
Transmitter set points will be specified for GSM and PCN when
typical values and statistical values become available.
Speech Codec
• Triple Rate (HR/FR/EFR) and Adaptive Multi Rate are
available as standard
Temperature
Range
• -10
0
C to +55
0
C (Normal operation)
• -30
0
C to +85
0
C (Storage capability)
