Siemens P2 - Connector Modifications; Enclosure Modifications; Remote Switch Modifications


Connector Modifications
Enclosure Modifications
Remote Switch Modifications
Box Height Enclosure Size
Inches
H W D
26 30 24 8
32 36 24 8
38 42 30 8
44 48 36 8
50 60 36 8
56 60 36 8
62 66 36 8
68 72 36 8
74 78 36 8
80 84 36 8
NEMA-4 For Type P2*
Water Tight, Dust Tight, Steel Enclosure
Table P2-18 – Application For Remote Switch*
Table P2-19 – Remote Control
Switch Modification*
Description
Auxiliary Contacts (Mounted Not Wired) Ea.
2-Wire Control
Table P2-17 – Control Power*
Transformer
Size VA
0,1 50
2 75
3 150
4 250
Table P2-15
NEMA-4X For Type P2
*
Water Tight, Dust Tight and Corrosion Resistant
Enclosure - Stainless Steel Enclosure - Fiberglass
and Steel with Epoxy Coating Size (inches)
Box Height
Inches H W D H D W
26 30 24 8 30 24 8
32 36 24 8 36 24 8
38 48 36 8 48 36 12
44 48 36 8 48 36 12
50 60 36 12 60 36 12
56 60 36 12 60 36 12
62 66 36 8 72 36 8
68 72 36 8 72 36 8
74 78 36 8 84 36 8
80 84 36 8 84 36 8
Table P2-16
Switch Type Modification
920 Adds 12” to unit space
911
≤ 225A adds 21” unit space >225 ≤400 Amps add 10” to width and 8” DP
minimum and 24” to height
30A adds 15” to unit space
LEN
>30A 100 adds 12” to unit space
7.7 Dp. Box min.
100 A ≤ 200 adds 12” to unit space and 10” DP. min.
*Contact local Siemens representative for any modifications.
