Siemens P2 - Kits and Accessories; Options for Type 1 & 2 Tubs; Option For 24 Wide Enclosures with Equal Gutter on Both Sides


Kits and Accessories
Table P2-20 – Standard Enclosures
Options for Type 1 & 2 Tubs
Add suffix "K" for enclosure c/w tub end wall with knockouts
Add suffix "KN" for enclosure c/w tub end wall with knockouts and gasketed
Add suffix "N" for enclosure gasketed
Add suffix "P" for enclosure painted std grey
Add suffix "PK" for enclosure painted std grey c/w tub end wall with knockouts
Add suffix "PKN" for enclosure painted std grey c/w tub end wall with knockouts and gasketed
Add suffix "PN" for enclosure painted std grey and gasketed
Add suffix "M" for metal card holder
Hinged trim - Replace "B" suffiz with "H"
Door-in-door - Replace "B" suffix with "D"
Metal card holder – Add “M” suffix
Option For 24” Wide Enclosures with Equal Gutter on Both Sides
24” wide with equal gutter on both sides - Add “24” as prefix
(1) For Silicon free enclosure, contact local Siemens representative.
Catalogue Number
Box
Type 1 Type 2 Type 3R/12 (1)
Height
Standard Trim Standard Trim Complete Enclosure
Inches Box Surface Flush Box Surface With Hinged Cover
26 B26 S26B F26B DSB52026 S26B WP26
32 B32 S32B F32B DSB52032 S32B WP32
38 B38 S38B F38B DSB52038 S38B WP38
44 B44 S44B F44B DSB52044 S44B WP44
50 B50 S50B F50B DSB52050 S50B WP50
56 B56 S56B F56B DSB52056 S56B WP56
62 B62 S62B F62B DSB52062 S62B WP62
68 B68 S68B F68B DSB52068 S68B WP68
74 B74 S74B F74B DSB52074 S74B WP74
Table P2-21 – Breaker Kits and Accessories (1)
Kit No. Description Contents
BBKB32AT BL/BQD 6-pole 3” branch breaker kit Kit contains top barrier, (3) A/C connectors, (1) B connector, hardware (Al/Tin)
BBKB32 BL/BQD6 6-pole 3” branch breaker kit Kit contains top barrier, (3) A/C connectors, (1) B connector, hardware (Cu/Tin)
BBKB32CS BL/BQD 6-pole 3” branch breaker kit Kit contains top barrier, (3) A/C connectors, (1) B connector, hardware (Cu/Silver)
BBKED32AT ED 6-pole 3” branch breaker kit Kit contains breaker support, inter-phase barriers, (3) A/C connectors, (1) B connector, hardware (Al/Tin)
BBKED32 ED 6-pole 3” branch breaker kit Kit contains breaker support, inter-phase barriers, (3) A/C connectors, (1) B connector, hardware (Cu/Tin)
BBKED32CS ED 6-pole 3” branch breaker kit Kit contains breaker support, inter-phase barriers, (3) A/C connectors, (1) B connector, hardware (Cu/Silver)
BBKQ1AT QJ branch breaker kit for 2 and Kit to contain all connectors and cover plates necessary to mount both 2 and 3-pole breakers (Al/Tin)
3-pole single mount
BBKQ1 QJ branch breaker kit Kit to contain all connectors and cover plates necessary to mount both 2 and 3-pole breakers (Cu/Tin)
BBKQ1CS QJ branch breaker kit for 2 and Kit to contain all connectors and cover plates necessary to mount both 2 and 3-pole breakers (Cu/Silver)
3-pole single mount
DFK1 BL, BQD, ED deadfront kit for Center strips 3”, 6”, 9,” 15,” 21” plus mounting hardware
1” pole breakers
DFFP3 Deadfront filler 3” 3” empty space filler and hardware
DFFP6 Deadfront filler 6” 6” empty space filler and hardware
BNK2 Branch neutral (P2) Three tier lug with mounting hardware to increase neutral capacity
P2BK1 P2 250A max. Bonding Kit Bonding strap and hardware
P2BK2 P2 400A max. Bonding Kit Bonding strap and hardware
P2BK3 P2 600A max. Bonding Kit Bonding strap and hardware
MHKP2 Truck kit for P2 Trim screws, clips, directory cards, ground bars, interior adjusting kit, bounding kit, number strip
BBKCED32 CED6 branch breaker kit Connector kit for P2, 24”W, 400A Cu/Tin bus only
BBKCED32CS CED6 branch breaker kit Connector kit for P2, 24”W, 400A Cu/Silver bus only
(1) For CED6 branch breaker kit, contact local Siemens representative
