Siemens PAD-3

21
Polarized Notification
Appliances
1
2
3
456
AE-30U
Note:
3 ohm max. total line resistance
of Notification Appliance Circuit
connecting wire.
37
38
CP-35
+
-
Input power
36
CP-35
Actuation input
67 89
2
1
3
Input 1
5
4
Input 2
PAD-3
AUX
18
NAC
12
Trouble
Relay
NAC
10 11
15
14
13
NAC
NAC
17
16
19
-
P/N 140-820405
24K EOL
Supervised
Notification
Circuit
Class B
5.6K 1/2W EOL
P/N 140-112166
-
- -
-
AC Fail
20
21
Figure 3-5. Connection to AE-30U
