Figure 4-3. Input 1 activates Outputs 1 & 2 and Input 2 activates Outputs 3 & 4
NOTE: Only the appliances connected to the same PAD-3 will operate synchronously when the output
circuits of the PAD-3 are set to synchronization mode. The appliances connected to a different
PAD-3 will not operate synchronously.
Figure 4-4. One Control Panel activating two PAD-3s
