Siemens RDD100.1RFS Wireless room thermostat with LCD CB1N1424en
Building Technologies 2017-11-21
RCR100RF
1) LED for indication of operating state
2) LEARN button (or override)
1
2
3
54
7
6
8
109
11
# Symbol Description # Symbol Description
1
Indicating that batteries need to
be replaced
7
Touchkey lock activated
2 Comfort mode
8
Display of zone (default is 1)
3 Economy mode
9
C
Room temperature in degrees Celsius
4
Display of room temperature,
setpoint, etc.
10
Heating On
5
F
Room temperature in degrees
Fahrenheit
11 Current room temperature
6
Protection mode (Protection
mode icon can be enabled via
parameter settings)
Display
