Siemens RDD100.1RFS Wireless room thermostat with LCD CB1N1424en
Building Technologies 2017-11-21
The receiver provides an override function (boiler test, emergency operation). It
allows the installer to override the relay to be permanently energized, regardless of
the wireless data received.
To activate the override function, press and hold the button for at least 10
seconds and release. The LED is constantly green and off once every 5 seconds,
indicating that the override function is enabled.
To disable the override function, press the button once.
Operating notes
The RDD100.1RF provides Comfort, Economy and Protection mode. The
difference between Comfort and Economy mode is only the room temperature
setpoint. The changeover between Comfort, Economy and Protection mode is
made by pressing touchkey .
When Comfort mode is activated, symbol appears on the display. The setpoint
(20 ºC) can be readjusted by pressing touchkeys + and –.
When Economy mode is activated, symbol appears on the display. The setpoint
(16 ºC) can be readjusted by pressing touchkeys + and –.
If the temperature falls below 5 ºC, the thermostat automatically activates the
heating output. Symbol appears only if the icon is enabled via parameter
settings.
Maintenance notes
Thermostat and receiver are maintenance-free.
Disposal
The device is considered an electronic device for disposal in terms of the
European Directive 2012/19/EU and may not be disposed of as domestic
garbage.
∂ Dispose of the device through channels provided for this purpose.
∂ Comply with all local and currently applicable laws and regulations.
∂ Dispose of empty batteries in designated collection points.
Comfort mode
Economy mode
Protection mode
