Siemens RDF301. / RDF301.50 / RDF600KN CE1N3171en
Building Technologies Semi flush-mount room thermostats with KNX communications 2012.10-04
Use ETS to assign the KNX group addresses of the RDF communication objects.
RDF301.50 has 2 switching groups with a pair of buttons each, which must be
configured via ETS. The switching groups only work on S-mode.
Each device has a unique KNX serial number inside the front panel. An additional
sticker with the same KNX serial number is enclosed in the packaging box. This
sticker is intended for installers for documentation purposes.
Disposal
This device is classified as waste electronic equipment under European Directive
2002/96/EC (WEEE) and may not be disposed of as unsorted municipal waste.
Adhere to all relevant national laws.
Regarding disposal, use the systems setup for collecting electronic waste.
Observe all local and applicable laws.
Technical data
Power supply
Rated voltage AC 230 V
Frequency 50/60 Hz
Power consumption
RDF301...
RDF600KN
Max. 4VA / 3.0W
Max 1.2VA / 3.5W
Outputs Fan control Q1, Q2, Q3-N
Rating
AC 230 V
Min. 5 mA, Max. 5(2) A
Control output Y11-N / Y21-N (NO)
Rating
Max. total load current through terminal “L” (Qx+Yxx)
AC 230 V
Min. 5 mA, Max. 5(2) A
Max. 7A
Inputs Multifunctional input X1-M/X2-M
Temperature sensor input:
Type
Temperature range
Cable length
Digital input:
Operating action
Contact sensing
Parallel connection of several thermostats
for one switch
Insulation against mains voltage (SELV)
QAH11.1 (NTC)
0...49 °C
Max. 80 m
Selectable (NO / NC)
SELV DC 0...5 V/max 5 mA
Max. 20 thermostats per
switch
4 kV, reinforced insulation
Function of inputs:
External temperature sensor, heating/cooling
changeover sensor, operating mode switchover
contact, dewpoint monitor contact, enable electrical
heater contact, fault contact, monitoring input
Selectable
X1: P38
X2: P40
KNX bus Interface type KNX, TP1-64
(electrically isolated)
Bus current RDF301
RDF600KN
20 mA
5 mA
Bus topology: See KNX manual (reference documentation, see below)
Assign KNX group
addresses
Switching groups
RDF301.50 only
KNX serial number
