Siemens RDG1... Wall-mounted room thermostats with LCD CE1N3181en
Building Technologies 2017-11-20
Use
The RDG1.. room thermostats are designed for use with the following types of system:
Fan coil units via On/Off or modulating control outputs:
∂ 2-pipe system
∂ 2-pipe system with electric heater
∂ 2-pipe system and radiator/floor heating
∂ 4-pipe system
∂ 4-pipe system with electric heater
∂ 2-stage heating or cooling system
Chilled/heated ceilings (or radiators) via On/Off or modulating control outputs:
∂ Chilled/heated ceiling
∂ Chilled/heated ceiling with electric heater
∂ Chilled/heated ceiling and radiator/floor heating
∂ Chilled/heated ceiling, 2-stage cooling or heating
Heat pumps with dx-type equipment:
∂ 1-stage compressor for heating or cooling
∂ 1-stage compressor for heating or cooling with electric heater
∂ 1-stage compressor for heating or cooling and radiator/floor heating
∂ 1-stage compressor for heating and cooling
∂ 1-stage compressor for heating and cooling with reversing valve
∂ 2-stage compressor for heating or cooling
