Siemens RUGGEDCOM RX1512

Device Management
3.3 Accessing the CompactFlash Card
3. Insert the CF card into the slot until it is fully seated.
2
3
1
1
CompactFlash Card
2
Access Panel
Figure3.3 Inserting the CF Card
4. Secure the CF card access panel to the chassis.
Removing the CF card
To remove the CF card from the device, do the following:
1. Make sure the device is powered down.
18
