Certification
6.2 EMC and Environmental Type Tests
Test
Description
Test Levels
Severi-
ty Levels
Shock
30 g @ 11 ms
Class 2
IEC 60255-21-2
Bump
10 g @ 16 ms
Class 1
IEC 60255-21-3
Seismic
Method A
Level 2
42
RUGGEDCOM RX1512
Installation Manual, 07/2019, C79000-G8976-1057
50
52
