RUGGEDCOM WIN5214
Installation Guide
Chapter 4
Technical Specifications
IDU to ODU Cable Specifications 29
Conductor Size 0.52 mm
Outer Jacket Material UV resistant FR-PVC
Outer Diameter 7.9 mm (0.31 in) nominal
Weight 68.0 kg/km
IDU to ODU Cable Design and Materials
Conductor Material Bare Copper
Conductor Size 24 AWG
Insulation Material Solid PO
Insulation O.D. 1.07 mm (0.04 in)
Color Code Per TIA/EIA 568-B
Overall Foil Shield Yes
Overall Shield Material Aluminum/Polyester Foil
Overall Foil Design 100% Coverage
Overall Drain-wire Material Tinned Copper
Overall Drain-wire Size 24 AWG
Overall Drain-wire
Construction
Stranded
Inner Jacket Material UV resistant FR-PVC
Inner Jacket Diameter 6.1 mm (0.24 in)
Total Number of Wires 8
IDU to ODU Cable Standards
Flammability Rating IEC 60332, UL1581 VW-1
Standards IEC 61156, TIA/EIA-568
IDU to ODU Cable Performance
Frequency Range 1 to 100 MHz
Impedance 100 Ω
DC Resistance 93 Ω/km nominal
Maximum DC Resistance 95 Ω/km @ 20 °C
Capacitance Unbalance 1.6 pF/m maximum
Velocity of Propagation 68% nominal
Propagation Delay Skew 35 ns/100 m maximum
Dielectric Strength 700 V/minute
