SCALANCE X-200
Compact Operating Instructions, 12/2010, A5E00813159-11
105
Dimension drawings
8
8.1 Dimension drawing
5
5
50
50
5
115
115
Figure 8-1 Dimension drawing SCALANCE X208, X206-1, X204-2, X202-2IRT, X204IRT,
X204-2LD, X206-1LD, X202-2P IRT, X202-4P IRT, X201-3P IRT, X200-4P IRT
