SCALANCE X-200
Kompaktbetriebsanleitung, 12/2010, A5E00813159-11
51
Maßbilder
8
8.1 Maßzeichnung
5
5
50
50
5
115
115
Bild 8-1 Maßzeichnung SCALANCE X208, X206-1, X204-2, X202-2IRT, X204IRT, X204-2LD,
X206-1LD, X202-2P IRT, X202-4P IRT, X201-3P IRT, X200-4P IRT
