Siemens SCALANCE X216 - Device Construction and Dimensions

SCALANCE X-200
Compact Operating Instructions, 12/2010, A5E00813159-11
95
Technical Specifications
7
7.1 Technical specifications
Table 7- 1 Construction
Device type
SCALANCE
Dimensions (W x H x D) in
mm
Weight in g Installation options
- DIN rail
- S7-300 standard rail
- Wall mounting
XF204 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X208 60 x 125 x 124 780 +
XF208 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X216 120 x 125 x 124 1200 +
X224 180 x 125 x 124 1600 +
X204-2 60 x 125 x 124 780 +
XF204-2 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X206-1 60 x 125 x 124 780 +
XF206-1 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X212-2 120 x 125 x 124 1200 +
X204-2LD 60 x 125 x 124 780 +
X206-1LD 60 x 125 x 124 780 +
X212-2LD 120 x 125 x 124 1200 +
X202-2IRT 60 x 125 x 124 780 +
X204IRT 60 x 125 x 124 780 +
XF204IRT 75 x 125 x 73 250 +
No wall mounting possible
No S7-300 standard rail mounting possible
X204 IRT PRO 90 x 125 x 124 1000 +
X202-2P IRT PRO 90 x 125 x 124 1000 +
X201-3P IRT PRO 90 x 125 x 124 1000 +
X202-2P IRT 60 x 125 x 124 780 +
X201-3P IRT 60 x 125 x 124 780 +
X200-4P IRT 60 x 125 x 124 780 +
