Siemens SED2 Series Getting Started Guide

6
Connecting Control Terminals (Default)
Anschließen der Steuerklemmen (Werkseinstellung)
Connexions de
commande
(Défaut)
Anslutning av styrkläm_
mor (fabriksinställning)
Tilkoblingsklemmer
for styresignaler
(Fabrikkinnstilling)
Default
Hz
+
ON
Hz
–
OFF
20 21
22
23 24 25
29 3017 26 27 2812 13 14 15 16
10 11678912345
ON
1
RL1
NC
RL1
NO
RL1
COM
RL2
NC
RL2
NO
RL2
COM
AOUT
1+
AOUT
1-
PTC
A
PTC
B
DIN
5
DIN
6
AOUT
2+
AOUT
2-
ISO
0V
P+ N-
RS-485
10V 0V AIN
1+
AIN
1-
DIN
1
DIN
2
DIN
3
DIN
4
ISO
24V
AIN
2+
AIN
2-
AIN1
On = [A], 0 - 20 mA
Off = [V], 0 - 10 V
AIN2
On = [A], 0 - 20 mA
Off = [V], 0 - 10 V
V: 0 - 10 V
2 - 10 V
I: 0 - 20 mA
4 - 20 mA
P1; N2 USS
Error
run
5192Z28en
DIN1 - I/O
DIN2 - Reverse
DIN3 - Fault acknowledge
