Siemens SED2 Getting Started Guide

4
Dimension Drawings
Maßbilder
Encombrements
Dibujos acotados
Disegni quotati
B / C
D / E / F
A
H
H
H
B
B
FSA FSB FSC FSD FSE FSF
mm
160
* 187
174
* 200
204
* 232
486 616,4
810
*1110
H
inch
6.3
* 7.3
6.9
* 7.9
8.0
* 9.1
19.1 24.3
31.9
* 43.7
mm
-
* 56
138
*120
174
* 156
235 235 300
IP20
B
inch
-
* 2.2
5.4
* 4.7
6.9
*6.2
9.3 9.3 11.8
mm
342,8 564
647 847 1112
H
inch
13.5 22.2
25.5 33.5 43.8
mm
230 312,7
310 310 400
IP54
B
inch
9.1 12.3
12.2 12.2 15.7
* including Foot Print
mit Unterbaufilter
Y compris le filtre
Incluyendo el filtro
Compreso il filtro
