Siemens SENTRON 7KT1681

Description
3.4 Parameterization
7KT multimeter
Manual, 08/2018, 2514284149-01
33
P05.01
OFF (hour counter deactivated): The device does not display the page for hour
counter measurement.
P05.02
•
OFF: The partial hour counter is not incremented.
•
ON: Partial hour counter is incremented when the device is measuring
energy.
•
If the partial hour counter is linked to one of the internal variables (LIMn),
the partial hour counter is only incremented if this condition is true.
P05.03
Channel number(n) of an
internal variable which was used in the previous
parameter.
Example:
If the partial hour counter needs to count the time while one measurement is
above a threshold that was defined by LIM3, program LIMx in the previous
parameter and enter "3" in this parameter.
M07 Communication for 7KT1682 only
Unit
Default
Range
P07.01
Address
–
01
01 … 255
P07.02 Baud rate bps 9600
• 1200
• 2400
• 4800
• 9600
• 19200
• 38400
• 57600
• 115200
P07.03 Data format – 8 bit - n
• 8 bit, no parity
• 8 bit, odd
• 8 bit, even
• 7 bit, odd
• 7 bit, even
P07.04
Stop bits
1
1 … 2
P07.05 Protocol Modbus RTU
• Modbus RTU
• Modbus ASCII
P07.03
Data format. 7-bit settings only available for the ASCII protocol.
P07.04
Number of stop bits
P07.05
Selection of communication protocol
