Siemens SENTRON 7KT1681

Description
3.4 Parameterization
7KT multimeter
32 Manual, 08/2018, 2514284149-01
M04 Integration
Unit
Default
Range
P04.01 Demand values – Shift
• Fixed
• Shift
• Bus (7KT1682)
P04.02
Power demand values
min 15 1 … 60
P04.03
Current demand values
P04.04 Voltage demand values 1
P04.05
Frequency demand values
P04.01
Selection of calculation mode
•
Fixed: The instantaneous measurements are integrated for the set time.
Every time this set time elapses, the integrated measurement is updated
with the result of the most recent integration.
•
Shift: The instantaneous measurements are integrated for a time = 1/15 of
the set time. Every time this interval elapses, the oldest value is replaced
by the newly calculated value and the integrated measurement is updated.
A time shift window with the 15 most recent calculated values which
correspond to the set time is taken into account here.
•
Bus: As a fixed mode; however, the integration intervals are defined by
means of synchronization messages sent on the serial bus.
P04.02
Demand value for active, reactive and apparent power
P04.03
Current integration time
P04.04
Voltage integration time
P04.05
Frequency integration time
M05 Hour counter
Unit
Default
Range
P05.01 Activate total hour counter – ON
• OFF
• ON
P05.02 Activate partial hour counter
• OFF
• ON
• LIMx
P05.03
Channel number (n)
1
1 … 4
