2-3
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C622-01
Step Activity Result
1. Select the configuration permanently
stored on the C7 by pressing
ENTER
Screens System
||>>
2. Select System with
F4
OpMode Language
||>>
3. Select OpMode with
F2
Operat. mode Online
4. Select the Transfer
function by pressing the two keys
simultaneously
Start the transfer with
SHIFT
ENTER
Operat. mode MPIDown
Ready for transfer
When you transfer the
configuration, it is loaded via
the MPI interface.
5. Now activate the transfer of the
configuration to the C7 on your
programming device/PC using
“ProTool/Lite”.
A soon as the configuration is
loaded, the message mode is set
and the configured standby
message is displayed.
6. You can now change to the following
modes
S C7 system function menu by
pressing the two keys
simultaneously
S Screens by pressing
0
SHIFT
ENTER
SIMATIC C7 Vx.xx
C7-621
If a configuration has already been loaded, you can start this by pressing the
ENTER
key and the configured “Start Screen” is displayed.
OP Configuration
Loaded
Startup
