2 Requirements for Use
B−11
CP 343-1 Lean for Industrial Ethernet / Manual Part B
Release 09/2009
C79000-G8976-C198-06
2.2 Configuration
The following version of STEP 7 is required:
Table 2-3
STEP 7 version
Functions of the CP
V5.2 or higher The range of functions of the CP 343-1 Lean (CX00) can be
configured.
V5.4 or higher Requirement for configuring the full functionality of the
CP 343-1 Lean (CX10 with firmware V1.0) including PROFINET
IO.
V5.4, Service Pack 5
+ HSP 1043
Requirement for configuring the new functions of the CP.
V5.4, Service Pack 5, Hotfix 2
+ HSP 1043
Requirement for configuring the new functions of the CP.
Installation of the Hardware Support Package (HSP)
You will find the HSP on the Internet at the following address:
www.siemens.com/automation/step7−hwconfig2
Install the HSP in STEP 7 / HW Config in the “Options” menu with the “Install
Hardware Updates” menu command. You will find further information in the STEP 7
online help (under “HSP” or “Hardware update”).
After installing the HSP, close STEP 7. After restarting STEP 7, the CP is in the
catalog of HW Config.
2.3 Programming
Programming − FCs / FBs
For some communications services, there are pre-programmed blocks (FCs/FBs)
available as the interface in your STEP 7 user program.
Please refer to the documentation of the FCs / FBs in the online help of STEP 7 or
in the manual /9/.
