Assembly and disassembly
5.5 DIN rail mounting
SCALANCE WxM766
Operating Instructions, 03/2022, C79000-G8976-C617-03
43
3. Press the device against the DIN rail until the DIN rail slider catch locks into place.
4. Connect the power supply, refer to the section "Power supply (Page 55)".
5. Fit the antennas, refer to the section "Antennas (Page 58)".
Uninstalling
1. Turn off the power to the device.
2. Disconnect all connected cables.
3. Pull the DIN rail slider down with a screwdriver
.
